  4. 330904-00-25-05-02-05 | Bently Nevada | Monitor Module
Sale!
SKU: 330904-00-25-05-02-05

330904-00-25-05-02-05 | Bently Nevada | Monitor Module

Request a Quote

330904-00-25-05-02-05 Product datasheet

Model number:

330904-00-25-05-02-05

Module Type：

3300 NSv Proximity Probe

Manufacture:

Bently Nevada

Condition：

Brand New

Range of Product:

3300 Proximity Transducer System

Lead time：

In Stock

Weight:

0.62 kg

HS CODE：

8537101190

Dimension:

28x28x4cm

MOQ:

1

Product Origin:

USA

System：

TSI

Discontinued on:

active

Communication Service:

Ethernet router

330904-00-25-05-02-05 Functional Description

The Bently Nevada 330904-00-25-05-02-05 3300 NSv Proximity Proberepresents a significant upgrade over previous 3300 RAM designs, offering superior chemical resistance for harsh process compressor applications. This system maintains full mechanical and electrical compatibility with legacy components while delivering improved side-view measurement characteristics and installation flexibility.

Engineered for reliability, the 3300 Series 330904-00-25-05-02-05features multiple thread configurations (1/4-28, 3/8-24, M8x1, M10x1) in both armored and unarmored variants. Its patented TipLoc molding and CableLoc design ensure exceptional durability, withstanding 220N (50lb) of cable pull force while maintaining signal integrity in challenging environments.

The Bently Nevada TSI Module 330904-00-25-05-02-05utilizes gold-plated ClickLoc connectors that positively lock in place, preventing loosening during operation. For maximum protection, the system supports optional connector protectors that shield electrical contacts from liquid intrusion and contamination in wet or washdown environments.

With its compact footprint and enhanced chemical resistance, the 3300 NSv Proximity Probe 330904-00-25-05-02-05excels in monitoring small-diameter shafts (<50mm) in refrigeration, process gas, and centrifugal compressors. The 330904-00-25-05-02-05 Proximity Probesdelivers reliable performance where standard proximity probes cannot be installed, making it indispensable for critical machinery protection.
