  4. 330902-00-60-10-02-05 | Bently Nevada | Monitor Module
Sale!
SKU: 330902-00-60-10-02-05

330902-00-60-10-02-05 | Bently Nevada | Monitor Module

Request a Quote

330902-00-60-10-02-05 Product datasheet

Model number:

330902-00-60-10-02-05

Module Type：

3300 NSv Proximity Probes

Manufacture:

Bently Nevada

Condition：

Brand New

Range of Product:

3300 Proximity Transducer System

Lead time：

In Stock

Weight:

0.1 kg

HS CODE：

8537101190

Dimension:

1.3×1.1x116cm

MOQ:

1

Product Origin:

USA

System：

TSI

Discontinued on:

active

Communication Service:

Ethernet router

330902-00-60-10-02-05 Functional Description

TheBently Nevada 330902-00-60-10-02-05 3300 NSv Proximity Probesis a specialized NSv proximity transducer system designed for machinery with tight installation constraints, such as centrifugal compressors and small-shaft applications. This system combines an NSv probe, armored extension cable, and XL NSv Proximitor sensor to deliver precise vibration/thrust measurements on shafts as small as 51mm (2″).

Engineers select the330902-00-60-10-02-05 Proximity Probes for its enhanced side-view capabilities and 1.5mm linear range, outperforming legacy 3000-series transducers. With an average scale factor of 7.87 V/mm (200 mV/mil), it excels in radial/axial position monitoring and Keyphasor® measurements where standard 5/8mm probes cannot fit.

TheBently Nevada 330902-00-60-10-02-05 Senor supports seamless upgrades from 3300 RAM systems while maintaining backward compatibility. Its compact design is ideal for counter-bore or rear-view installations on fluid-film bearing machines, particularly in refrigeration and process gas compressors.

For critical small-target applications, the Bently Nevada 330902-00-60-10-02-05 in Stockprovides API-compliant performance with improved temperature stability and interchangeability, ensuring reliable operation in space-constrained industrial environments.
