  4. Bently Nevada 330901-00-40-05-02-00 3300 NSv Proximity Probes
Sale!
SKU: 330901-00-40-05-02-00

Bently Nevada 330901-00-40-05-02-00 3300 NSv Proximity Probes

Request a Quote

Technical Overview

The Bently Nevada 330101-00-71-05-01-05 is a genuine 3300 XL 8 mm Proximity Probe designed for industrial automation systems. This high-quality component delivers reliable performance in demanding industrial environments.

Engineered to integrate seamlessly with Bently Nevada monitoring systems, it provides accurate data collection and monitoring capabilities essential for predictive maintenance and machinery protection.

Detailed Specifications

ParameterSpecification
ManufacturerBently Nevada
Part Number330101-00-71-05-01-05
Product Type3300 XL 8 mm Proximity Probe
ConditionBrand New
Warranty12 Months

Applications

  • Power generation turbines
  • Oil & gas compressors
  • Industrial rotating machinery
  • Predictive maintenance systems

Technical FAQ

Q: Is this a genuine Bently Nevada product?
A: Yes, this is a 100% genuine Bently Nevada product with full manufacturer warranty.

Q: What is the warranty period?
A: All products come with a standard 12-month warranty.
