SKU: ATV212HD75N4

Schneider Electric Altivar 212 ATV212HD75N4 75kW Variable Speed Drive

The Schneider Electric ATV212HD75N4 is a 75kW (100HP) variable speed drive optimized for HVAC and pumping systems. It features integrated BACnet/Modbus communication, 70% energy-saving technology, and a built-in EMC filter, providing a compact and efficient solution for building automation.

Operational Overview and Building Automation Efficiency

The Schneider Electric ATV212HD75N4 functions as a high-capacity frequency inverter specifically engineered for the Altivar 212 range. This drive specializes in managing three-phase asynchronous motors with a power rating of 75 kW (100 HP). By focusing on centrifugal pump and fan applications, the unit optimizes fluid management processes while drastically reducing energy overhead in commercial and industrial buildings.

Operating within a supply voltage range of 380V to 480V AC, this drive eliminates the need for complex harmonic mitigation hardware. Its unique design allows for immediate operation without external line chokes or DC chokes, thereby reducing installation costs and saving valuable space within electrical cabinets. Facility engineers rely on this model to maintain precise control over building environments while adhering to strict energy efficiency mandates.

Key Technical Characteristics and Performance

Advanced Energy Optimization: The drive implements specialized motor control algorithms that reduce energy consumption by up to 70% in variable torque applications.
Integrated Building Protocols: Native support for Modbus, BACnet, METASYS N2, and APOGEE FLN P1 ensures seamless communication with diverse Building Management Systems (BMS).
Thermal and Harmonic Management: Integrated technology reduces cable temperature rise and suppresses current harmonics, protecting the integrity of the local electrical grid.
Electromagnetic Compatibility: An internal Class C2 EMC filter comes standard, preventing interference with sensitive electronic equipment located nearby.
Resilient Construction: Featuring an IP21 rating, the drive supports vertical mounting configurations and tolerates standard industrial vibrations and temperatures.

Primary Industrial and HVAC Applications

The ATV212HD75N4 excels in environments where air and water movement are critical to operations. Consequently, it is frequently utilized for:

Commercial HVAC: Managing large-scale air handling units and ventilation fans in hospitals and data centers.
Pumping Systems: Regulating booster pumps and water circulation systems in high-rise buildings.
Cooling Infrastructure: Controlling cooling tower fans and condenser pumps to maintain thermal equilibrium.
Fluid Extraction: Optimizing suction and flow rates in specialized tertiary sector pumping applications.
