SKU: ATV930D30N4

Schneider Electric Altivar Process ATV930D30N4 30kW Variable Speed Drive

The Schneider Electric ATV930D30N4 is a 30kW Altivar Process variable speed drive designed for high-performance motor control in industrial environments. It features integrated Ethernet connectivity, 120% overload capacity, and an IP21 rating, making it ideal for the oil, gas, and water treatment industries.

Technical Summary and Operational Overview

The Schneider Electric ATV930D30N4 serves as a high-performance frequency inverter within the Altivar Process ATV900 range, specifically engineered to optimize industrial motor performance. This unit manages three-phase asynchronous and synchronous motors with a power rating of 30 kW (40 HP). By utilizing advanced motor control algorithms, the drive ensures precise torque and speed regulation for demanding industrial loads.

This model excels in process-oriented environments where reliability is mandatory. It incorporates a built-in braking unit and supports vertical mounting configurations. Furthermore, the drive features a robust design that allows for continuous operation in harsh industrial sectors, effectively bridging the gap between hardware power and digital intelligence.

Core Functions and Performance Characteristics

Advanced Load Management: The drive sustains a 120% overload capacity for 60 seconds, which facilitates the handling of applications with moderate torque requirements.
Comprehensive Motor Compatibility: It provides versatile control for various motor technologies, including permanent magnet motors and standard induction motors, ensuring high energy efficiency.
Network Resilience: Integrated cybersecurity features and redundant communication capabilities prevent total system failure during network interruptions.
Integrated Intelligence: An embedded web server provides real-time data access and logging, which simplifies remote diagnostics and predictive maintenance scheduling.
System Integration: Dual ports for EtherNet/IP and Modbus TCP allow the device to integrate seamlessly into complex PLC architectures and industrial IoT frameworks.

Industrial Applications

The ATV930D30N4 is strategically designed for heavy-duty sectors that require sophisticated fluid and material handling. Consequently, it is frequently deployed in:

Oil and Gas: Managing extraction pumps and processing equipment.
Mining and Minerals: Powering conveyors, crushers, and grinding mills.
Water and Wastewater: Controlling high-capacity submersible pumps and aeration systems.
Food and Beverage: Automating high-speed mixing and packaging lines.
