The ABB 3BHL000986P3016 5STP1752H0002 is a 1700V, 2000A IGCT module designed for HVDC and industrial drives. It features 20kA surge tolerance and superior thermal management. This brand-new Swedish power semiconductor ensures high-efficiency switching for Advant OCS and 800xA systems.
The ABB 3BHL000986P3016 5STP1752H0002 serves as a high-capacity Integrated Gate-Commutated Thyristor (IGCT). This semiconductor module manages heavy electrical loads in medium-voltage environments. It facilitates efficient power conversion by switching currents up to 2000A with precision. Furthermore, the unit provides critical protection in crowbar circuits and HVDC transmission systems. Its design bridges the gap between traditional thyristors and high-speed transistors. Consequently, this module ensures superior control for modern industrial energy grids.
| Feature | Specification Details |
| Model Number | 3BHL000986P3016 |
| Order Code | 5STP1752H0002 |
| Brand | ABB |
| Blocking Voltage | 1700 V |
| Nominal Current | 2000 A |
| Peak Surge Current | 20 kA (at 1ms) |
| Thermal Resistance | 0.02 K/W |
| Dimensions | 35 x 29 x 6.5 cm |
| Unit Weight | 2.56 kg |
| Origin | Sweden |
This IGCT module utilizes advanced Swedish manufacturing to handle extreme thermal stress. The low junction-to-case thermal resistance allows for rapid heat dissipation. Moreover, the robust press-pack housing provides mechanical stability during high-vibration operation. The module operates reliably across a wide temperature range from -40°C to +125°C. This thermal flexibility prevents hardware failure during continuous full-load duty cycles. Additionally, the compact 6.5cm profile fits standard high-power industrial cabinets perfectly.
Automation engineers deploy the 5STP1752H0002 in high-stakes infrastructure projects. It is a vital component for Flexible AC Transmission Systems (FACTS). Additionally, the module regulates power flow in large-scale renewable energy farms. Industrial facilities use these thyristors to stabilize medium-voltage motor drives. The module also performs effectively in grid stabilization and railway traction systems. Because it supports frequencies up to 500Hz, it optimizes energy efficiency in conversion. Therefore, it remains a standard choice for high-power density applications.
The 3BHL000986P3016 integrates easily into existing ABB Advant OCS and 800xA systems. Its low gate trigger voltage requirement simplifies the design of control electronics. Furthermore, the module meets stringent international safety and quality standards for power electronics. Brand-new units provide the longevity required for multi-decade infrastructure projects. Maintenance teams can replace these modules quickly to minimize system downtime. Every unit facilitates seamless global shipping through standard HS Code 8537101190 classification.
