GE IC694MDL645 Digital Input Module
The GE IC694MDL645, also cataloged as the IC694MDL645 Digital Input Module, operates as a dedicated hardware component for signal acquisition within PACSystems RX3i control networks. Incoming field signals are processed through sixteen discrete channels, and the resulting state data is transmitted to the backplane. Electrical compatibility with both positive and negative logic configurations is maintained, and operational states are continuously monitored via integrated LED indicators.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC694MDL645 |
| Brand | GE |
| Origin | USA |
| Weight | 0.3 kg |
| Dimensions | 3.5 cm x 13.2 cm x 13.5 cm |
| Operating Temp | Standard Industrial Range |
| Power Consumption | Backplane Dependent |
| Input Channels | 16 |
| Rated Voltage | 24 VDC |
| ON-state Voltage | 11.5 VDC to 30 VDC |
| OFF-state Voltage | 0 VDC to 5 VDC |
| Response Time | 7 ms (typical) |
PLC and Control Network Integration
System communication velocity and deterministic performance are regulated by the PACSystems backplane architecture. Signal integrity is preserved through high-level galvanic isolation, rated at 1500 VAC for one minute, whereby electrical noise interference is mitigated. Furthermore, firmware flash compatibility is ensured during module replacement, provided that the backplane remains energized within the specified voltage tolerances. The module is engineered for integration within both local and remote RX3i I/O racks, while support for RX7i systems is provided exclusively in distributed I/O configurations.Frequently Asked Questions
Q: Is the module capable of being hot-swapped while the system is powered?A: Yes, the module is designed to be extracted and inserted while the RX3i backplane is energized; however, field wiring must be verified to ensure no short-circuit conditions are created during the removal process.Q: How is the signal response time managed in high-speed applications?A: A typical response time of 7 milliseconds is imposed by the hardware filter circuits. This latency is inherent and should be accounted for when high-speed pulse capture is required.Field Installation Guidelines
- The module is to be mounted onto the designated RX3i backplane slot. A mechanical click is heard when the module is fully seated.
- Prior to wiring, the 24 VDC power supply must be verified for voltage stability.
- Signal wires are to be connected to the terminal block. A secure, firm connection is required to prevent intermittent signal loss caused by vibration.
- Shielding must be grounded at the designated earth terminal to ensure that electromagnetic interference is properly diverted.
- Once the module is seated and wired, the status LEDs are to be inspected for illumination corresponding to active field device states.
