Schneider Electric ATV630C22N4 Altivar Process 220kW Variable Speed Drive

Advanced Process Control and Operational Efficiency

The Schneider Electric ATV630C22N4 functions as a high-capacity frequency inverter within the specialized Altivar Process ATV600 range. This unit provides sophisticated management for three-phase asynchronous and synchronous motors, delivering a robust power output of 220 kW (300 HP). By integrating digital intelligence with power electronics, the drive allows operators to optimize fluid management and improve overall system transparency.

Operating across a 380V to 480V supply range, the drive utilizes an IP00 protection rating, which makes it ideal for mounting within custom control rooms or dedicated electrical enclosures. Furthermore, the system incorporates embedded energy-tracking tools that empower facilities to monitor real-time consumption and reduce operational expenses through precise speed regulation.

Technical Performance and Safety Integration

• Superior Motor Regulation: The drive implements sensorless flux vector control to maintain precise torque and speed accuracy without requiring external feedback hardware.
• SIL 3 Safety Compliance: To protect personnel and assets, the unit features built-in Safe Torque Off (STO) and Safe Limited Speed (SLS) functions that meet the highest industrial safety standards.
• Versatile Connectivity Options: Native Modbus TCP and CANopen interfaces facilitate immediate system integration, while optional Profinet and EtherCAT modules offer further architectural flexibility.
• Frequency Flexibility: It supports a broad output frequency range from 0.1 to 599 Hz and an adjustable switching frequency up to 16 kHz to minimize motor noise and heat.
• EcoStruxure Ecosystem: The drive connects seamlessly with SoMove software, which simplifies commissioning, diagnostic logging, and predictive maintenance scheduling.

Targeted Industrial Applications

Schneider Electric engineered the ATV630C22N4 specifically for heavy-duty process industries and large-scale utility management. Consequently, this model serves as a critical component in:

• Water Treatment: Regulating high-flow intake pumps, booster stations, and distribution networks.
• Mining and Metals: Driving heavy-duty slurry pumps and large ventilation fans for subterranean operations.
• Oil and Gas: Managing high-capacity transfer pumps and refinery cooling systems.
• Large Buildings: Controlling massive central chilled water systems and industrial-scale air handling units.

Technical Specifications

• Manufacturer: Schneider Electric
• Product Range: Altivar Process ATV600
• Model Designation: ATV630C22N4
• Power Rating: 220 kW / 300 HP
• Supply Voltage: 380V to 480V AC (Three-Phase)
• Protection Class: IP00 / UL Open Type
• Control Profiles: Asynchronous and Synchronous Motor Control
• Physical Weight: 172 kg (Approximate weight for 220kW frame size)
