Schneider Electric ATV930C22N4 Altivar Process 900 Variable Speed Drive

Product Overview

The Schneider Electric ATV930C22N4 is a high-performance Variable Speed Drive (VSD) from the Altivar Process 900 (ATV900) range, specifically engineered for maximum productivity and motor control precision. This 22 kW (30 HP) drive excels in demanding industrial applications that require advanced torque control and high-integrity communication. By integrating sophisticated motor algorithms and safety features, the ATV930C22N4 serves as a primary control solution for conveyors, crushers, and master/slave pump configurations in the mining, oil and gas, and wastewater sectors.

Advanced Motor Control and Connectivity

Engineers designed the ATV930C22N4 to manage both asynchronous and synchronous motors with exceptional accuracy. The drive supports complex automation architectures through built-in Dual Port Ethernet/IP and Modbus TCP protocols. Because the unit features an integrated web server and advanced data logging, maintenance teams can perform real-time diagnostics and energy monitoring directly from a standard browser. Furthermore, the drive incorporates network resilience services; if a communication link fails, the system maintains local control to prevent unplanned process shutdowns, thereby enhancing overall plant availability.

Key Technical Specifications

• Manufacturer: Schneider Electric
• Model Number: ATV930C22N4
• Product Series: Altivar Process ATV900
• Rated Power: 22 kW (30 HP)
• Input Voltage: 380V to 480V AC (3-Phase)
• Overload Capability: 120% for 60 seconds (Normal Duty)
• Enclosure Protection: IP00 (Designed for cabinet integration)
• Communication: EtherNet/IP, Modbus TCP, Modbus Serial
• Hardware Features: Integrated braking unit and STO (Safe Torque Off)
• Physical Weight: 1.9 kg (Note: Weight refers to specific internal control components; full drive chassis varies by configuration)
• Dimensions: 27.9 cm x 21.6 cm x 6.3 cm
• Origin: France

Versatility and Industrial Reliability

The ATV930C22N4 provides significant installation flexibility, supporting vertical wall mounting within a ±10° tolerance. To ensure longevity in harsh environments, the drive utilizes robust thermal management and high-quality internal components that resist electrical stress. The integrated braking unit allows for precise deceleration of high-inertia loads, while the comprehensive I/O set enables the drive to act as a localized controller. Consequently, this module reduces the burden on the central PLC, optimizing the performance of the entire safety-instrumented system.
