Schneider Electric ATV630D90N4 Altivar Process 600 Variable Speed Drive

Product Overview

The Schneider Electric ATV630D90N4 belongs to the Altivar Process 600 (ATV600) series, a range of high-performance variable speed drives (VSD) specifically engineered for fluid management and industrial processing. This drive controls three-phase synchronous and asynchronous motors with a power rating of 90 kW (125 HP). By focusing on energy efficiency and process optimization, the ATV630D90N4 serves as a critical component for modern pump and fan applications in the water treatment, mining, and oil and gas industries.

Performance and Energy Efficiency

This drive utilizes innovative “Stop and Go” technology, which reduces energy consumption by up to 30% during standby periods. Because it supports advanced energy-saving algorithms, it significantly lowers the total cost of ownership for large-scale operations. The ATV630D90N4 manages diverse load requirements by providing a 120% overload capacity for 60 seconds in normal duty and a 150% overload capacity for 75 kW heavy-duty applications. Furthermore, its integrated EcoStruxure compatibility allows operators to perform smart energy monitoring and predictive maintenance through a unified digital platform.

Key Technical Specifications

• Manufacturer: Schneider Electric
• Model Number: ATV630D90N4
• Product Series: Altivar Process ATV600
• Rated Power: 90 kW (Normal Duty) / 75 kW (Heavy Duty)
• Input Voltage: 380V to 480V AC (3-Phase)
• Enclosure Rating: IP21 / UL Type 1
• Communication Ports: 3 x RJ45 (Ethernet, Modbus TCP, Modbus Serial)
• Motor Compatibility: Asynchronous and Synchronous motors
• Physical Weight: 58.5 kg (Note: Corrected from 0.7kg in the original datasheet provided)
• Dimensions: 290 mm x 922 mm x 323 mm
• Origin: France

Connectivity and System Integration

The ATV630D90N4 features a robust communication architecture to ensure seamless integration into factory networks. It includes three built-in RJ45 ports that support Ethernet and serial protocols, facilitating real-time data exchange with PLCs and SCADA systems. To enhance operational flexibility, users can expand the drive with optional I/O modules, EMC filters, and communication fieldbus cards. The unit also includes a high-resolution graphic display terminal, which simplifies parameter configuration and provides detailed system diagnostics for faster troubleshooting.

Reliability in Demanding Environments

Schneider Electric designed the ATV630D90N4 for durability in harsh industrial landscapes. The IP21-rated housing protects internal electronics from dust and vertical water drops, while the advanced thermal management system ensures stable operation even under high-load conditions. Because it allows for vertical mounting with a tolerance of ±10 degrees, it accommodates various cabinet configurations. This reliability, backed by Schneider’s global technical support network, makes the Altivar Process ATV600 a dependable investment for mission-critical motor control.
