The Siemens 6ES7132-4BD02-0AA0 is a 4-channel digital output module for ET 200S distributed systems. It features 24V DC/0.5A outputs with short-circuit protection and a slim 15mm profile. Ideal for high-density actuator control.
The Siemens 6ES7132-4BD02-0AA0 serves as a standard digital expansion for the ET 200S distributed I/O series. This module provides four discrete output channels. Each channel handles 24V DC at a 0.5A rating. Its 15mm slim design allows for high-density terminal configurations. Consequently, it saves significant space in crowded industrial control cabinets. This unit effectively manages actuators and lamps in decentralized automation networks.
| Feature | Data Detail |
| Brand | Siemens |
| Order Number | 6ES7132-4BD02-0AA0 |
| Number of Outputs | 4 Digital Outputs |
| Output Type | Transistor (Source/P-switching) |
| Rated Load Voltage | 24V DC |
| Continuous Output Current | 0.5 Amps per channel |
| Aggregate Current | 2 Amps per module |
| Power Consumption | 0.8W (Typical) |
| Switching Frequency | 800Hz (Resistive) / 10Hz (Lamp) |
| Cable Length (Shielded) | 1000 Meters Max |
The 6ES7132-4BD02-0AA0 includes several safety features to prevent hardware failure. Built-in short-circuit protection triggers at a 1.5A threshold. Furthermore, the module limits inductive shutdown voltages to safe levels. This protects the internal circuitry when driving solenoid valves. A low quiescent current of 10mA ensures minimal heat generation during idle states. These robust characteristics provide long-term stability in harsh factory environments.
Integration into the SIMATIC DP network remains straightforward via the ET 200S interface. The module supports fast switching times for precise timing applications. For instance, it transitions from off to on in just 50 microseconds. Project managers benefit from the standard five-unit packaging format. This simplifies stock management for large-scale automation projects. Its high current capacity and redundant control capabilities make it a versatile industrial choice.
