The Emerson KJ3002X1-BG2 (VE4003S5B1) is an 8-channel thermocouple input module for the DeltaV M-series DCS. It features high-accuracy temperature sensing, cold junction compensation, and supports redundant configurations for mission-critical industrial applications.
The Emerson KJ3002X1-BG2 acts as a specialized temperature sensing interface within the DeltaV™ M-series I/O Subsystem. This 8-channel thermocouple module provides high-accuracy data acquisition for critical thermal processes. It enables precise monitoring by converting low-voltage sensor signals into actionable digital values for the DCS.
This module specifically manages millivolt inputs from various thermocouple types. The internal circuitry filters electrical noise to maintain signal purity. Furthermore, it performs cold junction compensation automatically to ensure temperature reading accuracy. This capability allows the DeltaV system to maintain tight control over thermal variables.
| Property | Details |
| Manufacturer | Emerson |
| Model Number | KJ3002X1-BG2 |
| Order Number | 12P1731X082 / VE4003S5B1 |
| Input Type | 8-Channel Thermocouple / mV |
| Platform | DeltaV M-series |
| Dimensions | 8.1 x 7.9 x 8.8 cm |
| Weight | 0.2 kg |
| Status | Discontinued (Available as high-quality spare) |
| Parameter | Specification |
|---|---|
| Model / Catalog No. | KJ2221X1-BA1 |
| Alternative Part Numbers | 12P3232X112 / VS6002 |
| Manufacturer | EMERSON (DeltaV Product Line) |
| Origin | USA |
| Weight | 0.32 kg |
| Dimensions | 4.1 x 12.5 x 19.0 cm |
| Module Type | SISNet Repeater Module / Network Extender |
| System Platform | DeltaV SIS Process Safety System (DCS) |
| Discontinued Date | December 31, 2018 (Legacy status) |
The Emerson DeltaV™ M-series KJ3002X1-BB1 (12P0683X092 / VE3006) is a legacy, high-precision thermocouple and mixed-signal I/O module designed for flexible process control within the DeltaV Distributed Control System (DCS). Capable of reading continuous analog variables alongside discrete status indicators, this modular card features built-in galvanic signal isolation, advanced thermocouple loop-burnout diagnostics, and high-density noise protection. Engineered for direct hot-swappable installation into M-series carriers, it delivers stable, industrial-grade data acquisition for critical temperature, flow, and pressure monitoring loops across harsh, high-interference manufacturing environments.
