Honeywell 8C-TPOX01 (51307022-175) Series 8 Wireless Module Backplane

The Honeywell 8C-TPOX01 (51307022-175) is a Series 8 wireless module backplane designed to provide reliable connectivity and structural support for wireless I/O in DCS architectures.

Request a Quote

Product Overview

The Honeywell 8C-TPOX01, identified by part number 51307022-175, serves as a dedicated wireless module backplane within the Honeywell Series 8 control architecture. This component provides the necessary mechanical interface and electrical connectivity for integrating wireless I/O capabilities into a Distributed Control System (DCS). Because it functions as the structural foundation for wireless communication modules, it ensures seamless data transmission between field-mounted wireless devices and the primary control network. Furthermore, the backplane simplifies the deployment of wireless sensor networks, which allows facilities to monitor critical process variables in geographically dispersed areas without extensive hard-wired cabling.

Technical Specifications

  • Model Number: 8C-TPOX01
  • Order Part Number: 51307022-175
  • Manufacturer: Honeywell
  • Product Series: Series 8
  • Module Type: Wireless Module Backplane
  • Dimensions: 14.5 cm x 12 cm x 5.5 cm
  • Weight: 0.16 kg
  • HS Code: 8537101190
  • Country of Origin: USA
  • Status: Active / In Stock

Functional Characteristics and Integration

The 8C-TPOX01 backplane facilitates the rapid integration of wireless I/O modules into the Series 8 platform. Because the backplane design prioritizes signal integrity, it effectively maintains communication stability between the I/O modules and the controller backplane. Moreover, the rugged architecture supports continuous operation in diverse industrial environments, which provides the reliability required for process automation.

Engineers rely on this backplane to scale their control systems without the constraints of physical wire runs. Additionally, the modular design permits fast hardware installation; consequently, maintenance teams can upgrade or replace modules with minimal disruption to ongoing operations. Furthermore, the backplane serves as a critical bridge for data packets arriving from field-deployed wireless sensors. Ultimately, by utilizing the 8C-TPOX01, businesses optimize their automation infrastructure, which improves system flexibility and enables the deployment of smart sensing technologies across the plant floor.

Tags: ,
