Honeywell 8C-TAIM01 51306999-175 Analog Intput Module

The Honeywell 8C-TAIM01, part number 51306999-175, functions as a high-precision Analog Input Module. It integrates specifically with the Series 8 I/O architecture within the Experion PKS environment. This module converts various field-level analog signals into digital data for the controller. Consequently, it provides the essential interface for real-time process monitoring. The hardware maintains superior signal integrity through advanced filtering and isolation circuits.

Input Capabilities and Performance

This module features 16 individual channels designed for industrial sensors. It primarily supports the standard 4-20 mA current loop interface. Furthermore, the 8C-TAIM01 handles signal conversion with high resolution and accuracy. This precision allows operators to track minute changes in pressure or temperature. The circuitry effectively rejects common-mode noise often found in industrial power plants. Additionally, the module performs continuous self-diagnostics to verify its internal health status.

Design and Industrial Integration

The 8C-TAIM01 utilizes the Series 8 vertical design for optimal cabinet density. It mounts directly onto the Input Output Termination Assembly (IOTA) base. This modular approach simplifies maintenance and allows for rapid module replacement. Moreover, the unit operates reliably across a temperature range of -20°C to +60°C. Its robust housing protects internal electronics from humid or dusty industrial conditions. The module also facilitates seamless data exchange with the central DCS.

Key Technical Specifications

• Manufacturer: Honeywell
• Model Number: 8C-TAIM01
• Order Number: 51306999-175
• Range: Series 8 I/O
• Input Channels: 16 Differential Channels
• Signal Type: 4-20 mA / 1-5 VDC
• Net Weight: 0.24 kg
• Dimensions: 14.5 cm x 12 cm x 5 cm
• Origin: United States
• Lifecycle: Active support available
