SKU: T8100C

ICS Triplex T8100C Trusted Controller Chassis

The ICS Triplex T8100C is a high-integrity Trusted Controller Chassis designed for SIL3-rated safety systems. It features a TMR-ready backplane and redundant power distribution to eliminate single points of failure. This 19-inch rack-mountable unit provides the essential foundation for fault-tolerant PLC operations in critical industrial environments.

Request a Quote

Product Overview

The ICS Triplex T8100C serves as the structural and electronic backbone for the Trusted Triple Modular Redundant (TMR) system. This Controller Chassis provides the physical housing, power distribution, and high-speed communication backplane necessary for SIL3 safety-rated applications. By integrating redundant power rails and a sophisticated voting bus, the T8100C enables the system to manage critical processes in oil and gas, chemical refining, and power generation without the risk of common-mode failures.

Core Functional Capabilities

  • Houses Triple Modular Redundancy: The T8100C provides dedicated slots for the TMR processor set, ensuring the hardware-based voting logic operates with maximum physical integrity.
  • Orchestrates High-Speed Data Exchange: The high-performance backplane facilitates rapid synchronization between the three redundant channels, which guarantees data consistency across the entire control loop.
  • Distributes Redundant Power: Integrated power busbars deliver reliable 24 VDC to all installed modules. This design prevents a single power supply failure from compromising the controller’s operation.
  • Enables Live Module Expansion: The chassis supports the addition and replacement of modules while the system remains under power. Consequently, operators can perform maintenance or upgrades without interrupting the safety function.
  • Structural Fault Isolation: Physical partitions within the T8100C protect against environmental and electrical interference between adjacent modules, further securing the fault-tolerant architecture.

Technical Specifications

  • Brand: ICS Triplex (Rockwell Automation)
  • Model Identifier: T8100C
  • Product Series: Trusted System
  • Equipment Type: TMR Controller Chassis
  • Safety Rating: SIL3 Certified (IEC 61508)
  • Net Weight: 5.24 kg
  • External Dimensions: 48.5 cm x 31.2 cm x 26.7 cm
  • Mounting Format: Standard 19-inch rack compatible
  • HS Classification: 8537101190
  • Origin: USA

Industrial Implementation

The T8100C Controller Chassis acts as the central hub for Emergency Shutdown (ESD) and Fire and Gas (F&G) systems. Because it meets the most rigorous international safety standards, engineers specify this chassis for hazardous environments where process continuity is non-negotiable. The modular design allows the system to scale from standalone safety nodes to enterprise-wide infrastructure protection, maintaining absolute process security at every level.
