HIMA HIMatrix F2DO801 Safety Remote Output Module

The HIMA F2DO801 is a safety-related remote output module featuring 8 relay outputs and safeethernet connectivity. Certified for SIL 3 and SIL 4 applications, it provides high-integrity switching for HIMax and HIMatrix safety systems.

Request a Quote

Product Overview

The HIMA HIMatrix F2DO801 is a high-integrity remote I/O module designed to expand the output capabilities of HIMax and HIMatrix safety controllers. Housed in a compact, rugged metal enclosure, this module facilitates remote field device control via safeethernet communication. It serves as a critical interface for actuating safety-related components such as valves, motors, and emergency stop circuits. Because it is a remote module, it does not execute independent user programs but rather acts as a slave device within a larger safety architecture.

Technical Functionality

Regarding its output capacity, the F2DO801 features 8 potential-free normally open (NO) relay outputs. These outputs are highly versatile, supporting switching voltages from 5 V up to 250 VAC or 250 VDC. The module operates on a standard 24 VDC power supply with a wide tolerance range of -15% to +20%. In order to ensure maximum system integrity, the module follows the “de-energize to trip” principle; should a system-level fault occur, all outputs automatically revert to a safe, de-energized state.

Furthermore, the module is engineered for rapid response times (typically $\ge 20$ ms), which is essential for preventing hazardous conditions in high-speed industrial processes. It includes internal monitoring that triggers a local FAULT LED and generates specific error codes that the main controller can use to initiate targeted safety reactions. While it primarily supports de-energize to trip, it is also adaptable for energized-to-trip safety applications when required by the process design.

Key Specifications

  • Manufacturer: HIMA
  • Series: HIMatrix
  • Module Type: Safety Remote Output Module
  • Output Channels: 8 Potential-free Relay Outputs (NO)
  • Switching Voltage: 5 V to 250 VAC / 250 VDC
  • Input Current: Maximum 0.6 A
  • Safety Certification: TÜV certified up to SIL 3 / SIL 4
  • Response Time: $\ge 20$ ms
  • Operating Temperature: Industrial standard rating
  • Dimensions: 4 x 19 x 12.8 cm
  • Weight: 0.3 kg

Installation and Maintenance

The module is designed for ease of integration into existing HIMatrix networks using safeethernet. It does not contain an internal backup battery, which simplifies long-term maintenance by removing the need for periodic battery replacements. For circuit protection, the module requires an external 10 A time-lag (T) fuse. Because it is rated for Ex-zone 2, it can be installed closer to field equipment in hazardous environments, reducing wiring costs and signal latency.
