SKU: PR6423/002-001 CON041

EMERSON PR6423/002-001 CON041 EPRO Series

The EMERSON PR6423/002-001 CON041 operates as a high-precision non-contact eddy current sensor for critical industrial machinery monitoring. We offer this Brand New, original stock component with fast global shipping to prevent unexpected downtime. Secure this discontinued spare part for your system today.

Configured for Specific Technical Task in System/Network Name, the EMERSON PR6423/002-001 CON041 (PR6423/002-001 Eddy Current Sensor) provides direct physical/electrical execution. The hardware operates by generating a high-frequency electromagnetic field to measure static and dynamic distances between the sensor tip and the target machine shaft. This non-contact physical displacement measurement transfers raw proximity data directly to connected machinery protection systems.

Hardware Specifications

Parameter	Specification
Model	PR6423/002-001 CON041
Brand	EMERSON
Origin	USA
Weight	0.18 kg
Dimensions	17 x 15 x 2 cm
Operating Temp	Standard industrial limits (exact range unspecified)
Power Consumption	Determined by driver/transmitter interface
Module Type	Eddy Current Sensor
Product Range	EPRO
System	DCS / TSI
HS Code	8537101190

Process Control & DCS Instrumentation Properties

The component interfaces via standard industrial loops, deploying eddy-current probe scaling protocols to deliver stable displacement signals. It utilizes channel-to-channel isolation mechanisms across the measurement path to prevent ground loop interference and suppress high-frequency electrical cross-talk in dense cable trays. The raw analog output matches predictable voltage variations across the calibrated physical gap, establishing native physical-layer compatibility with monitoring systems without intermediate conversion latencies.

Frequently Asked Questions

Q: Does this sensor module require an external driver or converter to output a 4-20 mA HART signal?

A: Yes. The PR6423/002-001 CON041 is an inductive proximity probe body that requires an external signal converter or driver to translate raw impedance shifts into calibrated analog loops or standard industrial monitoring voltages.

Q: What is the maximum recommended physical target gap for validation during setup?

A: Calibration parameters dictate standard linear range behavior. Physical gap voltages typically target -10 VDC center points depending on the specific machine protection system configuration and target material factors.

Field Installation Guidelines

Probe Tip Alignment: Mount the sensor body perpendicular to the observed machine shaft surface to eliminate angular measurement errors and tracking distortion.
Shielding and Grounding: Ensure the coaxial sensor cable shield is grounded at a single point, typically at the machine protection monitor chassis or junction box enclosure, to prevent inductive ground loops.
Cable Routing Constraints: Route the probe lead away from high-voltage AC power lines or variable frequency drive (VFD) output cables to minimize electromagnetic signal corruption.
Thread Engagement: When installing into threaded brackets or machine casings, maintain structural rigidity and observe proper torque constraints to prevent physical deflection or target contact.
