Siemens 6AV2124-0UC24-1AX0 / 6AV7424-7GA03-0AS0 HMI-PC Based System

The Siemens 6AV2124-0UC24-1AX0 / 6AV7424-7GA03-0AS0 powers advanced industrial visualization as a 15-inch PC-based HMI. It features Remote Operate V4.0 software, a high-resolution widescreen display, and seamless PLC integration. Engineered in Germany, this industrial touch panel provides the high-speed processing and rugged reliability required for complex automation and remote system monitoring.

Request a Quote

Product Overview

The Siemens 6AV2124-0UC24-1AX0 (bundled with the 6AV7424-7GA03-0AS0 component) anchors high-end industrial visualization strategies as a PC-based HMI solution. This 15-inch Comfort Panel hybrid bridges the gap between standard HMI functions and PC-level computing power. By merging high-resolution touch control with remote operation, this system empowers operators to manage complex automation architectures with precision and high data throughput.

Core Functional Capabilities

  • Renders High-Definition Visuals: The 15-inch widescreen display delivers a vivid, high-resolution interface for monitoring process parameters. This hardware ensures that operators identify alarms and system status changes instantly, even within complex graphical environments.
  • Powers Remote Operational Control: The system utilizes pre-installed Remote Operate V4.0 and OEM TP1900 PRO software to enable centralized management of distributed equipment. This allows engineers to monitor and adjust processes from a distance, which increases site safety and labor productivity.
  • Orchestrates Seamless System Integration: The PC-based architecture supports diverse industrial communication services, including Ethernet routing. These features facilitate effortless connections to existing PLC networks and higher-level IT infrastructures for real-time data exchange.
  • Maximizes Industrial Reliability: Siemens engineered this module for demanding environments, combining a slim 2.5 cm profile with a robust housing that resists industrial interference. The hardware maintains stable performance during continuous operation to ensure critical process uptime.
  • Accelerates Configuration and Deployment: The HMI-PC system operates within the TIA Portal environment, allowing developers to configure screens and logic efficiently. This unified engineering approach reduces the time required for system commissioning and maintenance.

Technical Specifications

  • Brand: Siemens
  • Model: 6AV2124-0UC24-1AX0 / 6AV7424-7GA03-0AS0
  • Module Type: HMI-PC Based System
  • Display Size: 15-inch Widescreen
  • Software: OEM TP1900 PRO / Remote Operate V4.0
  • System Compatibility: PLC-based Control Architectures
  • Networking: Ethernet Router / Industrial Networking
  • Net Weight: 0.95 kg
  • Physical Dimensions: 2.5 cm x 5.1 cm x 83.8 cm
  • Manufacturing Origin: Germany

Industrial Implementation

Industrial engineers integrate the Siemens 6AV2124-0UC24-1AX0 into sectors requiring high-density data visualization, such as automotive assembly, chemical processing, and advanced manufacturing. Because this unit functions as an HMI-PC hybrid, it excels in applications where operators run third-party Windows applications alongside automation software. This dual-capability eliminates the need for separate workstations on the factory floor and provides a single, ruggedized point of control for the entire production line.
