ABB CI541V1 3BSE014666R1 Profibus Interface Submodule

The ABB CI541V1 3BSE014666R1 is a 12 Mbit/s Profibus DP interface submodule for the AC500 PLC and S800 I/O system. Featuring dual-redundancy support and a compact 20mm design, it provides reliable, high-speed communication for critical industrial automation networks.

Request a Quote

Product Description

The ABB CI541V1 3BSE014666R1 is a high-performance communication submodule specifically designed for the AC500 PLC series and S800 I/O systems. This interface acts as a critical bridge, allowing ABB controllers to communicate with various field devices via the Profibus DP protocol. By integrating this module, operators can achieve high-speed, deterministic data exchange between the central processor and decentralized peripherals such as sensors, drives, and actuators.

Because the CI541V1 supports dual-redundant bus configurations, it is highly valued in industries where system uptime is non-negotiable. If one communication path fails, the module can automatically switch to the secondary line, preventing process interruptions. Furthermore, the module is engineered for easy “plug-and-play” installation into a communication terminal base, which significantly reduces commissioning time and simplifies maintenance in complex distributed control systems (DCS).

Moreover, the 3BSE014666R1 version is built with industrial-grade components to ensure stability under harsh electrical conditions. Its compact footprint (only 2cm wide) allows for high-density mounting on DIN rails, making it an efficient choice for space-constrained control cabinets. Whether used in water treatment, power generation, or factory automation, the CI541V1 provides the robust connectivity required for modern, data-driven industrial environments.

Technical Characteristics

  • Brand: ABB
  • Model: CI541V1 (Part Number: 3BSE014666R1)
  • Module Type: Profibus DP Communication Interface
  • Product Range: AC500 / S800 I/O System
  • Protocol: Profibus DP-V0 / DP-V1
  • Data Transfer Rate: Up to 12 Mbit/s
  • Redundancy: Supports Dual Redundant Bus Systems
  • Installation: Mounts on Terminal Base (e.g., TU510)
  • Physical Weight: 0.16 kg
  • Dimensions: 20 mm x 170 mm x 101 mm
