SKU: Z7116
HIMA Z7116 HIQuad X System Connection Interface Module
The HIMA Z7116 is a high-performance connection module for HIQuad X safety systems. Featuring 4 RS-485 ports and 2 CAN ports, this aluminum-housed module supports MODBUS and CANopen protocols, providing a lightweight and durable interface for critical industrial data exchange and signal termination.
Product Overview
The HIMA Z7116 serves as a specialized connection interface and cable termination module within the HIQuad X safety-related automation family. This German-engineered component bridges the gap between field instrumentation and the safety controller, ensuring high-integrity signal transmission. Although frequently associated with analog signal paths, the Z7116 acts as a critical communication node that facilitates data exchange across various industrial protocols. Its lightweight yet rugged aluminum alloy construction makes it a preferred choice for high-density cabinet installations where durability and shielding are paramount.
Technical Functionality and Connectivity
The Z7116 is designed to handle complex data flows by providing multiple high-speed communication ports. It integrates seamlessly with standard industrial networks, supporting both MODBUS and CANopen protocols to ensure interoperability with a wide range of third-party automation hardware. The module features an advanced port configuration, including four RS-485 serial interfaces and two CAN ports, allowing engineers to consolidate multiple data streams into a single, manageable interface point within the DCS architecture.
Key Technical Characteristics
- Manufacturer:Â HIMA
- Model Series:Â HIQuad X System
- Module Type:Â Connection Cable Interface / Signal Termination Module
- Material:Â Industrial-grade Aluminum Alloy
- Communication Ports:Â 4 x RS-485, 2 x CAN
- Protocol Support:Â MODBUS, CANopen
- Operating Temperature: -20°C to +60°C
- Physical Dimensions:Â 20 mm x 60 mm x 103 mm
- Net Weight:Â 0.08 kg
- Standard Compliance:Â CE, UL, and ISO 9001 certified
- Installation:Â Plug-and-play interface for HIMA subracks
Industrial Applications
Professionals deploy the HIMA Z7116 in safety-critical sectors that require reliable, real-time data monitoring and device networking. Common applications include:
- Interfacing analog sensors with digital safety logic in chemical plants
- Facilitating MODBUS communication between field devices and the safety PLC
- Managing distributed I/O networks in oil and gas refineries
- Providing shielded termination for CANopen-based actuator control
- Centralizing serial communication within a Safety Instrumented System (SIS)
