GE Fanuc IC697CPX772 Digital I/O Module

The GE Fanuc IC697CPX772 is a 96 MHz 80486DX4 CPU module for the Series 90-70 PLC. It features 512 KB RAM, floating-point math support, and three serial ports. This 32-bit controller handles 2,000 I/O points with high-speed 0.4 µs logic execution.

Request a Quote

The GE Fanuc IC697CPX772 acts as a high-performance 32-bit controller for the Series 90-70 PLC platform. This module manages complex automation tasks using a 96 MHz 80486DX4 microprocessor. It provides rapid execution speeds for demanding industrial processes. The unit processes Boolean logic instructions in only 0.4 microseconds. Consequently, this CPU ensures high productivity and precise timing in synchronized systems.

Computational Power and Memory Capacity

This controller includes 512 KB of user RAM for program storage and data logging. Additionally, the hardware features 256 KB of non-volatile flash memory for firmware protection. An integrated floating-point math unit enables the module to solve advanced mathematical equations. This capability is essential for PID loops and analog scaling. The internal Real-Time Clock maintains scheduling accuracy within 3.5 seconds per day. Memory remains secure for six months via the IC697ACC701 lithium battery.

Communication and Scalability

The hardware supports extensive I/O capacities to accommodate large-scale machinery. It manages up to 2,000 discrete inputs/outputs and 8,000 analog words. Three versatile serial ports facilitate seamless connectivity with external devices. Port 1 utilizes an RJ11 interface for standard RS-232 communication. Ports 2 and 3 use 15-pin D-shell connectors for RS-485 networking. Furthermore, the module supports industry protocols like RTU, SNP, and SNPX.

Technical Specifications Summary

SpecificationDetails
Microprocessor80486DX4 (96 MHz)
Logic Execution0.4 microseconds per Boolean step
RAM / Flash Memory512 KB / 256 KB
Current Consumption3.1 Amps from 5V Bus
Operating Temperature0°C to 60°C (32°F to 140°F)
Diagnostic Indicators7 LEDs for status monitoring
Dimensions4 x 21.8 x 29.3 cm

Operational Features

Users can configure the operating state through a three-position front panel switch. This allows for manual control over RUN and STOP modes. Seven diagnostic LEDs provide immediate visual feedback on system health. These indicators track memory protection status and CPU errors. The module mounts easily into any standard Series 90-70 rack. It withstands harsh vibrations and electrical noise common in factory environments.
